10G DWDM SFP+ modules single mode dual fiber LC EMS 40KM for FTTH Solution
- Model Number:OFS-10G-LR
- Type:Wiredlan sfp
- Place of Origin:Guangdong, China
- Brand Name:Optfocus
- Connector Type:LC
- Warranty:1 Year
- Features:High-performance
- transmission distance:10km
- wavelength:1310nm
- fiber type:simple fiber
- Date Rate:10G
- Keywords:sfp module
10G DWDM SFP+ modules single mode dual fiber LC EMS 40KM for FTTH Solution
Hot Pluggable&Full Compatibility 10G SFP+
Description
OPTFOCUS SFP+ transceiver are multi-purpose optical modules for 10Gbit/s data transmission applications at 850nm, 1310nm and 1550nm. The transceivers are ideally suited for datacom and storage area network (SAN/NAS) applications based on the IEEE 802.3ae and Fibre Channel standards, Fiber Channel 10G, 8.5G, 4.25G, 2.125G, 1.0625G, 10G BASE-SW/SR/LR/ER, 1000 Base-SX Ethernet.
Product Feature
lCompliant to SFP+ Electrical MSA SFF-8431
lCompliant to SFP+ Mechanical MSA SFF-8432
lMulti rate of up to 11.3Gb/s
l10G Ethernet compliance
lTransmission distance up to 80km (SM fiber)
lLow power consumption
l0C to +70C case operating temperature range
lLaser Class 1 IEC / CDRH compliant
lRoHS 6/6 compliant
lCompliant with product safety standards
Order Information
P/N | Data Rate | Distance | LD | PD | DDMI |
OFSP-316G-02 | 6.25Gbps | 2km | 1310nm FP | PIN | Y |
OFSP-316G-10 | 6.25Gbps | 10km | 1310nm DFB | PIN | Y |
OFSP-318G-02 | 8.5Gbps | 2km | 1310nm FP | PIN | Y |
OFSP-318G-10 | 8.5Gbps | 10km | 1310nm DFB | PIN | Y |
OFSP-858G-015 | 8.5Gbps | 150m | 850nm VSCEL | PIN | Y |
OFSP-8510G-03 | 10Gbps | 300m | 850nm VSCEL | PIN | Y |
OFSP-1310G-2 | 10Gbps | 2km | 1310nm FP | PIN | Y |
OFSP-1310G-10 | 10Gbps | 10km | 1310nm DFB | PIN | Y |
OFSP-1510G-40 | 10Gbps | 40km | Cooled EML | PIN | Y |
OFSP-1510G-80 | 10Gbps | 80km | Cooled EML | APD | Y |
Compay Profile
Shenzhen Optfocus Technology Co.,Ltd was established in 2009, which is a National High-tech Enterprise integrating with R&D, manufacturing, marketing and service to our worldwide partners and customers.
OPTFOCUS with more than 13 years’s experience focus on high-performance fiber optical communication solutions&products,network security monitoring transmission solutions& products.FTTH/FTTx Access solutions&products.
