FTTH new original ZTE F660 V5.0 onu gpon WIFI ont 1GE 3FE 1POTS WIFI 1USB ZTE ZXHN F660 V8.0
F660
minimum order
1 piece
Quantity
- Model Number:F660
- Type:ONU
- Place of Origin:Guangdong, China
- Brand Name:OPTFOCUS
- Use:broadband access
- Warranty Time:1Years
- Network:Wireless Lan, Wired LAN, wifi, 4g
- Model:F660
- UNI:1*GE+3*FE+1*Phone+1*USB+1*WiFi(5dibi)
- Version:8.0
- Firmware/Interface:English
- NNI:GPON
- Optical Connector:SC
- Dimensions (L *W *H):23*15*8cm
- Application:FTTH FTTB FTTX Network
- Color:White GPON ONU
- Material:PC+ABS
FTTH new original ZTE F660 V5.0 onu gpon WIFI ont 1GE 3FE 1POTS WIFI 1USB ZTE ZXHN F660 V8.0
Functional characteristics
- Fiber access:Connecting internet throungh GPON access method
- Ethernet fuction: It Provids 4 Ethernet ports and Ethernet devices can be directly connected to the ZXHN F660 Ethernet port to achieve Internet and IPTV services.
- VoIP function: It Provids 1 VoIP(Phone) ports supporting softswitch SIP, IMS SIP or H.248 voice control protocol and telephone can be connected via this interface.
- Internal WLAM fuction: Users can connect to the ZXHNF627 via WLAN, enabling wireless Internet access.
- Data sharing, fast backup, data recovery and other functions: It provides USB2.0 port.Pluging a USB memory device,it can achieve all these fuctions.
- Under the premise of providing the above functions ,achieving security, QoS and network management are also took into the consideration.
- Providing multi-level authentication based on device, user, service, and encryption of data channels
- For different service requirements of the business,it can complete the local equipment and network matching QoS requirements
- Holding network management based on multiple management methods
Executive Standard
- GPON interface: SC/UPC or SC/APC PON interface,GPON standard
- Ethernet interface: 1*10Mbps/100Mbps/1000Mbps adaptive port+3*10Mbps/100Mbps adaptive port,RJ-45 type,IEEE802.3 and IEEE802.3u standard
- Phone interface: RJ-11 type
- WLAN interface: IEE802.11b,IEEE802.11g,IEEE802.11n standard,built-in antenna
- USB interface:standardized USB2.0
Please send the inquiry soon ! we are your most sincere partner!
| Basic technical data | |
| Manufacturer | ZTE |
| Model | ZXHN F660 V8 |
| GPON features | Optical port: 1 x GPON interface (SC/PC) |
| Transmission distance: 20 km | |
| Transmission speed | |
| - download: 2.488 Gb/s | |
| - upload: 1.244 Gb/s | |
| User network interface | 1 x 10/100/1000 Base-T, half/full duplex, auto MDI/MDIX, auto negotiation |
| 3 x 10/100 Base-T, half/full duplex, auto MDI/MDIX, auto negotiation | |
| 1 x POTS interface | |
| 1 x Wi-Fi interface: IEEE 802.11b/g/n 2.4 GHz | |
| 2 x Wi-Fi antennas | |
| 1 x USB 2.0 host interface | |
| Optical module | Reception: 1480-1500 nm |
| Transmitting: 1290-1330 nm | |
| Receiver sensitivity: -28 dBm | |
| Transmitter optical power: 0.5 to 5 dBm | |
| Main features | |
| Supported services | VoIP, Internet, IPTV |
| GPON | 8 x T-CONT, 32 x GEM port |
| VLAN | 802.1Q, 802.1P, 802.1ad |
| MC address table | 1K |
| L3 functions | DHCP server/client, DNS client, NAT |
| IPv6 | Double stack, DS-Lite |
| VoIP | SIP/H.248, G.711/G.722/G.279, T.30/T.38 |
| Wi-Fi | 4 x SSID, 2x2 MIMO, WPS |
| Wi-Fi authentication | Common Key, 128-bit WEP, WPA-PSK, WPA2-PSK, WPA2-Enterprise |
| Multicast | IGMP v1/v2/snooping/Proxy, MLD v1 snooping |
| Multicast group per user port | 256 |
| QoS | Flow classification for services based on physical ports, MAC address, VLAN ID, VLAN priority level, IP address, SP/WRR/SP WRR |
| Management | Local Web, OMCI, TR069 |
| USB | DLNA DMS, USB backup, 3G/LTE adapter |
